PRODUCT

Model Focal Length Sensor Size Field of view Resolution Spec sheet
D H V
54422MAS
5.4mm 1/3" 61.2 49.8 37.7 1.2MP
18610P-AS
1.85mm 1/4" 137.5 110.0 82.8 VGA
B47616BMC
4.7mm 1/1.4" 56.8 47.7 29.5 3MP
18513AS
1.8mm 1/4" 140.0 110.0 84.5 VGA
18524MAS
1.8mm 1/3" 177.6 154.2 87.0 1.3MP
15422AS
1.5mm 1/4" 181.4 139.4 103.0 VGA
12624MAS
1.2mm 1/3" 210.0 192.8 122.8 1.3MP
VIR80620-3M
8.0mm 1/2.7" 46.3 40.6 23.2 3MP
VIR60620-3M
6.0mm 1/2.7" 64.4 55.8 31.0 3MP
29620-3M
2.9mm 1/2.7" 140.5 119.8 65.1 3MP
10620MAS
0.9mm 1/4" 196.0 190.5 150.8 1.3MP
